Gold finger tape, also known as polyimide tape, is a polyimide film used as a substrate to coat high-performance silicone pressure-sensitive adhesives on one side. High-precision coating reaches ± 2.5um, no scratches, drawing and other phenomena, good shear, easy punching die-cutting process, with excellent high temperature resistance and solvent resistance!
Item No :
S0619BProduct Origin :
DONGGUANColor :
AmberLead Time :
15 Working daysWidth :
2-1000mmThickness(mm) :
0.06mm-0.3mmLENGTH :
33m or customized
Products Description
Polyimide polymers film exhibits an excellent balance of physical, chemical, and electrical properties over a wide temperature range.
Application
1. In the SMT process, the thermocouple wire shall be pasted when measuring the temperature of the reflux furnace;
2. In the SMT process, it is used to paste the flexible circuit board (FPC) on the fixture, so as to carry out a series of processes such as printing, patch and testing;
3. It can be wrapped on the cable and used as insulating tape;
4. It can be pasted on the connector for picking up materials by the mounter, so as to replace the iron sheet;
5. It can be die cut into any other shape for some special purposes.
Physical Properties
| Product name | Heat resistant transfer sublimation reflective kaptone tape high temperature insulation polyimide tape |
| Total Thinckness | 0.03mm,0.05mm,0.055mm,0.06mm,0.08mm,0.1mm,0.12mm,0.15mm and so on. |
| Width | From 1mm to 500mm/1000mm and so on. |
| Length | 33M,66M,100M,200M,500M and so on. |
| Heat Resistance | Short term 280 degrees, Long term 260 degrees |
| Peeling Strengthto Steel Plate |
MIN 5.0N/25MM |
| Tensile Strength |
MIN 115N/25MM |
| Elongation Break |
MIN 50% |
Contact To Us
Tel: +86-13332606223
Email：sales1@senmatech.com
Please scan the QR code and add me to serve you!
Gold finger tape, also known as PI tape or PI tape, is a tape made of polyimide film as the base material and imported silicone pressure-sensitive adhesive. It has high and low temperature resistance, acid and alkali resistance, solvent resistance, electrical insulation (H grade), radiation protection and other properties.
